ART T8 - 8 Channel Transformer / Isolator - Ground Hum Eliminator

ART T8 - 8 Channel Transformer / Isolator - Ground Hum Eliminator
$339.99
$449.00
Sold Out

The T8™ (Transformer Eight) a high quality totally passive audio interface that uses 8 transformers to separate input and output signal grounds, thereby isolating two systems and reducing hum and ground-loop noise.

Be The First To Review This Product!

Help other SWAMP Industries users shop smarter by writing reviews for products you have purchased.

Write a product review

High-Quality 8 Channel Transformer / Isolator, Passive Audio Interface

Clean and Neutral Sound
The T8™ (Transformer Eight) a high quality totally passive audio interface that uses 8 transformers to separate input and output signal grounds, thereby isolating two systems and reducing hum and ground-loop noise. The T8's audio transformers have flat and wide frequency response and handle high signal levels while maintaining an isolated balanced output. This gives the T8 a very clean and neutral sound with a wide variety of signal sources. The transformers are wound for 1:1 unity gain and are designed to be used with impedances from 600 Ohms to 100k Ohms.

Versatile Connectivity
Connection versatility sets the T8 apart from other isolation boxes. The T8 provides balanced XLR, 1/4" phone, and RCA type phono connections on all inputs and outputs simultaneously. The T8 fits easily into virtually any audio system and is a clean patch point between all types of systems.

Flexible Mounting Options
The T8s mounting ears are reversible so you can have either the XLRs on the front or The 1/4" and RCA phono jacks on the front. This maximizes flexibility in cabling your system. Whether you need an interface between a computer based audio workstation and your monitor system, isolation on long cable runs in a fixed installation, isolation of multiple signal sources from your recording equipment, or in many cases, just a safer connection between two audio systems, the T8 can accommodate.

The ART T8's full feature set, rugged construction, and high-end specifications make it the obvious choice for Live Sound, Permanent/Fixed Install, D.J., and virtually any PA application.

ART (acronym: Applied Research & Technology) are renowned for producing devices that feature unique gadgets and functions that make you think "Why hasn't anyone thought of that before?"

Features and Specifications:

  • High-quality, passive audio interface
  • 8 high performance transformers
  • XLR, 1/4" phone, and RCA type phono connections on all inputs and outputs.
  • Reversible rack mount ears
  • Separate input and output signal grounds reduce hum
  • Audio transformers have an extremely flat and wide frequency response
  • Very clean and neutral sound with a wide variety of signal sources
  • Can be used for signal taps or as a signal splitter
  • Use as a safer connection between two audio systems (ie: Computer workstation or monitor system)
  • 19" 1U black all steel case

Technical Specifications:

  • Frequency Response - 10Hz -50kHz, +/-.5dB @ +4dBu
  • Phase Shift - Phase Error: Less than 5&186;, 20Hz - 20kHz
  • CMRR - 60dB typical
  • Power Requirement - Completely Passive
  • Dimensions - 1.75"H x 19"W x 3.75"D
  • Weight - 3.75 lbs

Owner's Manual


Custom Label: ART-T8

SKU: ART-T8

Shipping Weight: 1.4300
