JOYO JF-09 Tremolo Guitar Effect Pedal

JOYO JF-09 Tremolo Guitar Effect Pedal

The Tremolo pedal is an ultra clean sounding guitar effect pedal that will produce the classic tremolo sound originally reserved for the classic old school blues amps.

By: on 31 August 2015
The unit produces a nice smooth effect with good tone that I haven't been able to achieve thus far
(5)

Write a product review

JOYO Tremolo Pedal
The Tremolo pedal is an ultra clean sounding guitar effect pedal that will produce the classic tremolo sound originally reserved for the classic old school blues amps. Easily adjustable to create super fast or super slow and subtle tremelo that are euqlly effective when run through the clean channel on your amp with an overdrive pedal to introduce that real old country style distortion sound for more harder edged tones.

Optical Tremolo with Adjustable Parameters
The JF-09, is an easy, optical tremelo pedal to use, and doesnt posess all the needless bells and whistles other similar pedals do. With only two knobs - intensity, which is another word for level of effect, and the Rate, which determines the speed of the tremelo effect - nothing else is really needed to create the wavering and emotive tones that tremolo's are renowned for.The optical LED display lets you seethe speed of the rate, allowing you to adjust so that sound is modulated at exactly the correct speed for your playing.

Features

  • Yellow with Black Knobs
  • Silver True Bypass switch
  • Intensity and Rate Controls
  • 1/4" jack input and outputs
  • LED active light
  • Aluminum alloy casing with stoving varnish finish

Specifications

  • Input Impedance: 500k Ohms
  • Output Impedance: 10k Ohms
  • Delay Time: 0.9ms to 6.4ms
  • Speed Range: 0.4Hz to 8Hz
  • Running Current: 20mA
  • Power: 9V DC adapter or 9V Battery
  • Weight: 290g
  • Dimensions: 118 (L) x 64 (W) x 38 (H), 60 (H incl knobs) mm

PDF Manual


Custom Label: JY-JF-09

SKU: JY-JF-09

Shipping Weight: 0.3500
