Alctron MP8 V2 8-Channel Microphone Pre-Amplifier
The Alctron MP8 V2 is a professional 8-channel microphone/line preamplifier designed for pro studio and live sound applications, yet affordable enough for home project studios. Clean pre's, 74dB amplification, 48V switchable per channel, TRS jack outputs.
Alctron MP8 V2 8-Channel Microphone Pre-Amplifiers
The Alctron MP8 is a professional 8-channel microphone/line preamplifier designed for pro studio and live sound applications, yet affordable enough for home project studios. Clean pre's, 55dB amplification, 48V switchable per channel, TRS jack outputs.
Ideal for Home Studios
The Alctron MP8 solves many of the connectivity problems arising in studio and live sound applications from using increasingly popular digital audio interfaces which often only consist of unbalanced line inputs or very low (or no mic pre) gain structure for the balanced input stage and with no available phantom power. Featuring 8 totally independent high quality mic preamps in the one unit. Also features 48V phantom power on each channel, low cut, pad and phase buttons and all the inputs are combo jacks.
Features:
- Professional 8-channel mic/line amplifier
- The chassis is made from high quality steel to provide extra shielding against stray magnetic and RF
- Each channel features independent gain control and LED indicator to avoid distortion
- Standard XLR/JACK combo input
- Phantom power with individual on/off switches for each channel and LED indicator
- Low cut, phase and pad buttons on each channel
Specifications:
| AUDIO INPUTS & PRE AMPS | |
| Connectors | XLR/JACK combo input |
| Type | Balanced |
| Impedance | 2k Ohms Min |
| Sensitivity | -40dB |
| Peak input level | +5dB |
| Gain control range | 30dB Peak |
| Amplification | 55dB |
| Phantom power | +48V, switchable |
| AUDIO OUTPUTS | |
| Connectors | 1/4'' TRS jack |
| Type | TRS Balanced |
| Impedance | 600 Ohms |
| Peak output level | +18.5dB |
| Distortion | 0.02% |
| response | 20Hz~20kHz, 0dB~-2B |
| S/N Ratio | Better than 80dB |
| Crosstalk rejection | >70dB@1kHz; -20dB input |
| APPLICATIONS POWER SUPPLY | |
| Power Requirements | selectable, ~ 100-120 VAC,~ 200-240 VAC, 50-60 Hz |
| Fuse | 100-120 VAC: 630 mA (slow-blow)200-240 VAC: 315 mA (slow-blow)100-240 VAC: 500 mA (slow-blow)5X20mm glass type |
| Power cord connector | Standard IEC receptacle with built-in fuse holder |
| Dimensions | 44.5mm x 482.6mm x 217mm |
