JOYO JW-02 Digital 5.8GHz Wireless Guitar System

JOYO

JOYO JW-02 Digital 5.8GHz Wireless Guitar System

includes Transmitter and Receiver

$114.07
$123.99
  Sold Out
Found a better Price? Price match now
or interest free for up to 6 months with
Contact us for an ETA
SAVE 8%

With its 5.8GHz frequency band design, the JW-02 provides a calm assurance of no signal loss. It has a transmission distance of 20 metres, and can be setup to be used with multiple receivers. Internal battery lasts for 5 hours.

Dispatch

JW-02 Digital 5.8GHz Wireless Guitar Transmitter and Receiver
With its 5.8GHz frequency band design, the JW-02 provides a calm assurance of no signal loss. It has a transmission distance of 20 metres, and can be setup to be used with multiple receivers. The internal battery lasts for 5 hours.

5.8GHz Frequency Band
The design of the JW-02 to use this frequency band guarantees superior anti-jamming ability, better transmission stability and faster signal transmission than the traditional 2.4GHz wireless products at the same transmission distance. There is so much traffic in the 2.4GHz in many city venues that signal frequency interference becomes less in the 5.8GHz frequency band, which enhances signal transmission quality.

Great Specs and Features
JW-02's signal distortion is less than 0.04%, and delay is less than 7ms. Apart from the normal one transmitter to one receiver function, the JW-02 also features one transmitter to multiple receiver function, and with this you can have the advantage of creating unique setups for your instrument tone. A maximum of 4 sets of JW-02 can be used simultaneously.

Features:

  • 5.8GHz frequency band design
  • Transmission distance of 20 metres
  • One transmitter to multiple receiver function
  • Signal distortion less than 0.04%
  • Channel switching option to reduce interference from external signals or phones
  • Anti-jamming method: adaptive frequency hopping
  • Sample rate is 24-bit/48KHz
  • Delay less than 7ms
  • 3.7V, 500 mAh battery, lasts 5 hours
  • Plug and play, user friendly

Specifications:
Transmitter

  • Built-in lithium battery
  • Battery: 3.7V 500mAh
  • Transmit power: 7dBm
  • Operating frequency: 5.8GHz frequency band
  • Frequency response: 20Hz-20KHz
  • Delay: <7ms
  • Power: DC5V/500mA
  • Input Impedance: 220KΩ
  • Plug’s type: 6.35mm mono plug
  • Dimensions: 38*50*114mm
  • Weight: 49g

Receiver

  • Built-in lithium battery
  • Battery: 3.7V 500mAh
  • Reception sensitivity: -85dBm
  • Received frequency: 5.8GHz frequency band
  • Signal distortion: <0.04%
  • Gain: 0 dB
  • SNR: 105 dB
  • Frequency response: 20Hz-20KHz
  • Delay: <7ms
  • Power: DC5V/500mA
  • Output Impedance: 100Ω
  • Plug’s type: 6.35mm mono plug
  • Dimensions: 40*20*129mm
  • Weight: 50g
View PDF brochure for JOYO JW-02 Digital 5.8GHz Wireless Guitar System

Joyo 5.8 ghz wireless system

By: Anonymous on 7 November 2018
The system has been working fine so far. And on an active bass instrument wise. The devices paired up to one another perfectly straight out of the box. It does produce an audible pop when switching to tune mode via Tc electronics mini noir tuner at the start of a pedal chain. It's not a big deal or something that is going to break the deal personally. From many reviews of many other systems, it's not like it is an isolated case of an audible pop created via a pedal chain. For the price it is really great sound/tone wise. The units are equipped with gold plated jacks also. Which is a great bonus, again considering price range etc. Would recommend this device to anyone looking for a budget wireless system for guitar/bass. I initially ordered the xvive system and didn't read all the product info overly thorough. And found that the xvive system doesn't work properly and isn't recommended for use with active instruments. Swamp called me in reply to my email sent overnight. And were extremely helpful in recommending this as a more suitable wireless system to be used with my active/passive Yamaha TRBX 504 bass. I am not disappointed with the system by any means in any way. I just turn down the volume on my bass when switching the polytune mini noir into tuner mode. It reduces the volume of the audible pop. This may be a deal breaker for some people, but for myself personally I can cope with it via way of reducing the volume present etc. I also wouldn't hesitate to recommend it to friends or others as an option worth considering and trialling. With Swamps 30 day no questions return policy, it's even more of an incentive to try the system out and see if it might be for you. Just follow Swamps guidelines for 30 day returns by keeping all your products packaging etc and you potentially can't lose. It's a great little system.
