Alctron DMC01 Passive Studio Monitor Controller

$62.99
In Stock

The Alctron DMC01 is a versatile passive studio monitor controller in a compact desktop format. It is designed to allow precise adjustment of monitoring levels from your audio device. Switch for mono signal and muting. Combo jack inputs and TRS outputs.

Alctron DMC01 Passive Studio Monitor Controller
The Alctron DMC01 is a versatile passive studio monitor controller in a compact desktop format. It is designed to allow precise adjustment of monitoring levels from your audio device. Switch for mono signal and muting. Combo jack inputs and TRS outputs.

Versatile Passive Monitor Controller
Having a versatile passive monitor controller in your home studio setup is vital for quick workflow. It is designed to allow precise adjustment of monitoring levels from your audio device to your monitors. You could also use it with CD players, pre-amps and mixers. The unique passive circuit design for a high quality signal path, delivers attenuated signal, with full transparency and no influence on the origianl signal. It features combo XLR/TRS and TRS, as well as 3.5mm jack, mute switch, mono toggle (merges the stereo output signal into a mono master signal) and a large rotary volume control.

Features:

  • Versatile passive monitor controller
  • Designed to allow precise adjustment of monitoring levels from analog audio sound
  • Unique passive circuit design for a high quality, unaltered signal path
  • Mono and mute toggles and large rotary volume control
  • Features combo XLR/TRS and TRS, as well as 3.5mm jack

Specifications:

  • Input connectors 1: 2 x combination XLR/TRS 1/4’’
  • Input connectors 2: 1 x 1/8’’ mini jack
  • Max input level:    +26dB
  • Input impedance:    5k ohms
  • Output connectors 1: 2 x TRS 1/4’’
  • Max output level:    >+26dB
  • Output connectors 2: 1 x 1/8’’ mini jack
  • Impedance:           0-5k ohms
  • Frequency response: 20hz-20khz
  • Signal to noise: better than -120dB
  • Channel cross talk: >-80dB
  • Distortion:<0.0004%
  • Dimensions :118mm X 112mm X 46mm
  • Weight: 342g
View PDF brochure for Alctron DMC01 Passive Studio Monitor Controller
