JOYO JF-33 Analog Delay Guitar Effect Pedal
By: Paul Fail on 1 January 2016As usual prompt and efficient service. Pleasure to deal with both online and telephone.
JOYO JF-33 Analogue Delay Pedal for Guitar
The Analogue Delay effect revolutionised rock guitar playing in the mid 60's by introducing the slapback, echo and multiple overlapping repeats to many a guitarists sound heard on so many albums. This style of delay pedal became integral to the sound of bands such as U2 and The Police and many others. The JOYO JF-33 is an analogue delay pedal that will do exactly the same thing to guitar solo's, psychedelic sounds, and melodic motifs and hooks as were done by the original delay machines in the 60's. Featuring three separate controls, the user will be able to set the pedal to replicate the style of delay they desire to create their favourite sound.
Time, Mix and Repeat Controls
The JF-33 has three controls that can be easily adjusted and configured for the particular type of delay required. All knobs turned to the left will produce the most subtle, barely audible effect, where as turning everything to the right will result in continual overlapping delay and warping of the signal for the ultimate disturbingly psychadelic effect. The time control will adjust the amount of time between the original note played and the echo, whilst the repeat knob will set the amount of times the echo of the note will repeat. The Mix control is similar to a volume of the delay, where turning it to the right will increase the mix, or level of the delay in comparison to the clean unaffected sounds.
True Bypass Switching
The JF-33 has true bypass switching that eliminates any signal interference when switching the pedal on or off. The Analogue Delay pedal can be used with an AC adapter (optional) or 9V Battery.
- Green with Black Knobs
- Silver True Bypass switch
- Time, Mix and Repeat Controls
- 1/4" jack input and outputs
- Aluminum alloy casing with stoving varnish finish
- Input Impedance: 1MΩ
- Output Impedance: 1kΩ
- Running Current: 40mA
- Power: 9V DC adapter or 9V Battery
- Weight: 200g
- Dimensions: 118mm (L) x 64mm (W) x 50mm inc switch (H)
Custom Label: JY-JF-33
Shipping Weight: 0.2400
