• Canare DA206 110 Ohm AES/EBU Digital Audio Cable - BLUE - Per Metre

    $7.10
    $7.89
    In Stock
    SAVE 10%
    Sale Ends:

    1 metre of - Blue colour industry standard 110 ohm cable, the DA206 consists of twisted pair conductors with an external braided shield allowing for a flexible cable that reduces the possibility of signal interference.

    1 Metre Of - Canare DA206 110 Ohm AES/EBU Digital Audio Cable - Blue - 100 metre roll
    Robustly constructed by one of the worlds leading cable manufacturers, this cable is a smart choice for all professional digital audio applications. The DA206 consists of twisted pair conductors with an external braided shield allowing for a flexible cable that reduces the possibility of signal interference.

    Designed to carry Digital Signals- AES/EBU or DMX
    The DA206 was designed as a dual purpose cable, that can carry either digital audio (AES/EBU) or DMX lighting signals.

    This listing is for 1 Metre (1m) of cable. For custom length, purchase multiple quantity.

    Features:

    • Twisted Pairs with Braided Shield
    • Special PE Filter Rods maintain constant 110 ohm impedance

    Applications:

    • AES/EBU Digital Audio
    • DMX Lighting
    • Audio Rack Wiring
    • Post Productions

    Specifications:

    • Maximum recommended AES/EBU length: 1,180ft (360meters).
    • Jacket color: BLUE

    MECHANICAL SPECIFICATIONS

    Model Std.
    Lng.

    ft.
    (m)
    Wt.
    Std. Lng.

    lbs.
    (kgs)
    Nom.
    O.D.

    in.
    (mm)
    PVC
    Jacket
    Nom.
    Thick.
    in.
    (mm)
    Brittle
    Point


    (C°)
    No.
    of
    Cond.
    Insul.
    Type*
    Thick

    mil
    Cond-AWG
    (Qty./mil)
    Cross Sec.
    Area
    mm²
    Pitch
    of
    Quad
    in.
    (mm)
    Shield
    Cover-
    age
    DA206 328
    (100)

    656
    (200)
    17
    (8)

    35
    (16)
    .287
    (7.3)
    .035
    (0.9)
    -56
    (-49)
    2
    ORG
    WHT
    IPE
    30.3
    AC-#20
    (7/12.60)
    0.56
    - >95%
    Braid

    *Dielectric Strength = 500V AC/1min. Insulation Resistance/3Mft = >1000M ohm.

    ELECTRICAL PERFORMANCE
    Model Cond.
    D.C.R.

    ohm/1000ft
    (ohm/100m)
    Shield
    D.C.R.

    ohm/1000ft
    (ohm/100m)
    Nom.
    Cap.
    ***
    pF/ft
    (pF/m)
    Nom.
    Cap.

    pF/ft
    (pF/m)
    Nom.
    Imp.

    ohm
    Nom.
    Atten.
    @3MHz

    dB/100m
    Group
    Delay
    Time
    nS/ft
    (nS/m
    DA206 <10.1
    (<3.3)
    <4.3
    (<1.4)
    14.6
    (48)
    22.3
    (73)
    110 2.2 -

    ***Capacitance between conductors.
    †Capacitance between conductors to shield.

    View Specifications

    View PDF brochure for Canare DA206 110 Ohm AES/EBU Digital Audio Cable - BLUE - Per Metre
