Empress Effects Buffer+ Analog I/O Interface Pedal with Boost

$299.99
Back-order - Dispatched after 30 days
If your prefer to wait until the stock has arrived:
CLICK HERE TO 'GET NOTIFIED' once we have stock on hand
RRP $395.00

Maintain the highest fidelity of your guitar/bass signal over long cable runs, and add extra boost when required with the Empress Effects Analog Buffer+. Featuring a 30dB boost, analog signal path, use this to ensure the highest signal through your pedals

Empress Effects Buffer+
Maintain the highest fidelity of your guitar/bass signal over long cable runs, and add extra boost when required with the Empress Effects Analog Buffer+. Featuring a 30dB boost, analog signal path, use this to ensure the highest signal through your pedals

Highest Quality Buffer
Signal loss due to long, un-buffered cable runs is an issue that has plagued guitar players for decades. The primary goal of the buffer+ is to eliminate this signal loss, ensuring that your tone is unchanged by your cables. Additionally, all the connectivity of your pedal board is consolidated to make set up quick and easy. The buffer+ also has a very handy set of features that make life just a little better. Noise filters, input pads, switchable clean boost and input loading are all powerful tools available on the buffer+.

Handmade in Canada.
2-Year Warranty, extended to 4 Years when you register online.

Features:

  • All Analog Signal Path - no digitals in here!
  • Small Size - delightfully small when considering all the features packed into this unit
  • Tuner Out - Separate tuner output keeps your tuner out of the audio path
  • Complete I/O - All the connections to your pedalboard consolidated in one place. Makes setup and teardown quick and easy
  • Switchable Boost - Dial in up to 30dB of clean boost and switch on and off with the soft touch foot switch
  • Tuner Mute - Hold the footswitch for a second and mute the amp output for tuning
  • Noise Filters - Similar to Dolby's noise filter technology, choose between 2 different noise filters to remove any unwanted noise from your effects chain
  • Input Pad - Pad or boost the input by 3dB. Great for matching outputs of different guitars, reducing really hot active pickup signal or boosting the signal to your effects to improve signal to noise ratio
  • Input Loading - Load down your pickups a little, a lot or not at all. It's up to you

Specifications:

Input Impedance 1Meg
Output Impedance 510 Ω
Frequency Response (-3dB)    5Hz - 40kHz
Power Input Voltage 9V DC (Negative tip)
Power Input Connector 2.1mm barrel connector (Negative tip)
Power Consumption 86mA
Total Harmonic Distortion 0.02%
Signal to Noise Ratio 105.3dB
Headroom +9.4dBu
Enclosure Material Die Cast Aluminum
Input connectors 1/4" Jack
Output connectors 1/4" Jack
Height (enclosure) 1.25"
Height with controls 50mm
Length 114.3mm
Width 63.5mm
Weight 250g
View PDF brochure for Empress Effects Buffer+ Analog I/O Interface Pedal with Boost
