• Alctron H8n 8-Channel Headphone Amplifier

    with 3 Stereo Inputs

    $229.99
    In Stock

    The Alctron H8n is an ultra-versatile 8-channel headphone amplifier. It has 3 sets of balanced stereo signal inputs, allowing for different headphone mixes. Mono or Stereo selectable. Great for studios, and stages, anywhere that requires clean H/P signals

    Alctron H8n 8-Channel Headphone Amplifier
    The Alctron H8n is an ultra-versatile 8-channel headphone amplifier. It has 3 sets of balanced stereo signal inputs, allowing for different headphone mixes. Mono or Stereo selectable. Great for studios, and stages, anywhere that requires clean H/P signals

    8 Headphone Connections
    Each channel has the separate volume control and level peak LED indicator, which adjust the level to both headphone and parallel line outputs. There are three balanced, line-level input channels with capacity to distribute one input signal to all headphones or group the headphone outputs (depending upon input configuration) for monitoring flexibility. By virtue of the mono/stereo selector switches, one headphone can monitor 2 different MONO signal sources. It will meet all kind of monitor requirement.

    Features:

    • 8 totally independent stereo high-power amplifier sections in one rack space
    • Output level control and accurate 8-digit LED output meter per channel
    • Independent amplify circuit rejects interference and mix of each channel
    • Adopts JRC performance chip to amplify the signal, also ensures low distortion and low noise
    • 3 sets stereo balanced input, 8-channel stereo output, each channel featuring independent volume control

    Specifications:

    Connectors 1/4’’TS
    Type unbalanced\
    Impedance 47KΩ
    Max output level +25dB
    Output impedance 22Ω
    Gain 12.5dB
    Distortion 0.02%
    Frequency response 20hz-20khz
     S/N ratio >80dB
    Crosstalk rejection >68dB@1khz; 20dB input
    Volume per channel, variable
    Signal selector per channel, variable
     AC requirements  selectable, 100-120V AC, 200-240V AC, 50-60HZ
    Fuse 100-120V AC:1000mA;200-240V AC:500mA
     Power cord connector standard IEC receptacle with built-in fuse holder
    Size 44.5mm * 482.6mm * 217mm



    View PDF brochure for Alctron H8n 8-Channel Headphone Amplifier
