The Alctron MP100 V2 is a hybrid tube and solid state microphone preamp, which is modelled on the UA 710. Featuring a high quality 12AX7B tube, you can mix between the tube and FET signal to achieve your optimum sonic tone. Heavy duty shielded case.
| Loading... | ||||||
Alctron MP100 V2 Hybrid Tube and Solid State Microphone Amplifier
The Alctron MP100 V2 is a hybrid tube and solid state microphone preamp, which is modelled on the UA 710. Featuring a high quality 12AX7B tube, you can mix between the tube and FET signal to achieve your optimum sonic tone. Heavy duty shielded case.
Classic Design and High Quality Build
Alctron MP100 V2 is a brilliantly flexible mic preamp with both tube and solid state signal output. You can blend seamlessly between the tube and solid state signal to achieve the sound you want. The sonic signal can be pure and precise, but also powerfully coloured when you want it. It can be driven hard when you need the little extra gain. It has separate input and output control, 70dB gain and a pad on the input. A DI input on the front is extrememly handy for direct connection of guitars, basses, and line signals. In a practical half rack format with handle and black VU meter in front, it is ideal to record on the move, and keep your signal chain professional.
Features:
- Hybrid tube and solid state microphone amplifier
- Heavy duty chassis provides extra shielding against stray magnetic and RF
- Features Tube/FET mixing and MTR button
- Adopts 12AX7B tube DI circuit design to premium performance
- Large front panel mic gain knob
- Features 48V phantom power
Specifications:
- Input: XLR and 1/4’’ jack
- Output: XLR
- Tube complement: 12AX7B
- Pad: -15dB
- Max power consumption: 160mA @120VAC, 20W
- Power requirements: 100-240VAC
- Mic input impedance: 2Kohm
- Line input impedance: 10Kohm
- Hi-Z input impedance: 2.2Mohm
- Internal output impedance: 600ohm
- Gain range: 70dBu
- Mic gain range: 10-60dBu
- Line gain range: -10-40dBu
- Hi-Z gain range: -10-40dBu
- Mic frequency response: 20hz-20khz
- Line frequency response: 20hz-20khz
- Hi-Z frequency response: 20hz-20khz
- Min THD + noise @+4dBu: 0.1% tube 0.005%
- Dimensions:
- Front Plate Width: 210mm
- Front Plate Height: 90mm
- Body Width: 210mm
- Body Depth: 275mm
- Body Hieght: 82mm
