JOYO R-08 Cab Box Modelling and IR Loader Pedal
R-08 Cab Box Modelling and IR Loader Pedal
A unique pedal, the Cab Box provides 4 tube power amp simulations, 20 cabinet models and 11 mic models. It also lets you load up 10 Impulse Responses at any one time to expand the sounds available, and this is done using the included Joyo PC software. An extremely useful pedal.
Cabinet Emulator, and More
The JOYO CAB BOX is a guitar cabinet emulator, a guitar effect pedal that allows full configuration of vintage and modern amps. You can configure the power amp, cab simulations, microphone type and distance, EQ, midi control and loading & editing of 3rd party IR files. The Cab box makes everything about recording or performing so much easier and authentic with a massive array of adjustable parameters to achieve the custom guitar set up of your choice. It has a straightforward and user friendly interface that fits on the pedalboard, it offers full configuration and eliminates complex menu options found on amps, tablets and computers. The sound of vintage and modern amps is at your feet.
An IR is an impulse response (IR, for short) its a sound measurement that takes into account the conditions around a guitar cabinet speaker, including the room, microphone and mic preamp. The JOYO Cab box works with third party IR files, simply connect to the pc/mac via USB for IR loading using the JOYO Cab software. With the JOYO Cab Box IR loader, in addition to 20 preset saving locations, you can store 10 additional third party IRs, Using the software you can load or delete third party IRs and then apply these to the Cab box emulation.
JOYO R-Series Pedals
The Revolution Series of guitar pedals are the 4th generation of guitar effects from JOYO, and have some very cool design features. Amongst them all is the ambient lighting on the bottom and the top of the pedal casing that is new to the pedal game, making it stand out in the dark. These pedals are built to take rugged situations.
- 4 tube power amps - select and edit the tube parameter, Select tubes from 6L6,6V6,EL34 or EL84
- 20 cabinet models
- 11 classic microphone models - adjusting microphone model, microphone type, microphone angle position & distance
- 3 fully configurable post EQs for guitar, bass & parametric. With settings for Gain & Attentuation, Q value, Low & High Pass filtering. The 5 band EQ is fully customisable, setting the 5 bands from 80hz to 11khz and level adjustments as required for each
- 20 preset IR loading and an additional 10 loading memory banks for third party IR
- 128 cab memory slots to save all of your presets
- Control buttons: Master Volume, Parameter Select, Power Amp, Cab/Mic, EQ, SAVE, HOME, LED Toggle
- Dimensions: 130mm x 110mm x 50mm
- Weight: 418g
- Input Impedance:2.2M
- Output Impedance: 47
- Rated current: 300mA
Firmware Update currently available. Click here for further information and download links.
