Neutrik NAC3FXXA-W-S powerCON Cable Connector - Power IN - Blue

Outer Diameter - 6mm-12mm

$15.49
RRP $18.00
  In Stock
Buy In Bulk & Save!
Buy 2 to 10: Pay $14.95
Buy 11 to 19: Pay $14.45
Buy 20 or more: Pay $13.98
-
+
Finance Available
PayPal Checkout
Afterpay

Neutrik's NAC3FXXA-W-S is a lockable power connector, designed for use as the "Power IN" connector on a power cable. Features easy to use screw terminals, coloured blue to distinguish from Speakon cables and for cable diameters 6mm - 12mm.



Dispatch

Neutrik NAC3FXXA-W-S powerCON Cable Connector - Power IN - Blue OD - 6mm-12mm
Neutrik's NAC3FXXA-W-S is a lockable power connector, designed for use as the "Power IN" connector on a power cable. Features easy to use screw terminals, coloured blue to distinguish from Speakon cables and for cable diameters 6mm - 12mm.

powerCON XX Series
This is a locking AC mains cable connector, keyed and colour coded (blue) for power-in, screw terminal assembly. The powerCON FXXA/FXXB is a single phase (3 conductor) lockable power connector with Circuit Breaking Capability when mated with powerCON XX Series receptacles. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed to guarantee a safe power connection.

Features:

  • IEC EN 60320-1 / UL 60320-1 / CSA  C22.2 No. 60320-1 certified, thus accepted as a component for cord sets acc. to IEC 60799 / UL 817 and equipment acc. to IEC 62368-1
  • Ergonomic design with slip-proof two-component molded housing
  • Power-in (blue) and power-out (grey) versions with different keying to avoid the possibility of intermating
  • Unique NEUTRIK locking bushing and strain relief for cable diameters 6 mm to 12 mm
  • Easy to assemble because the strain relief locks with the insert mechanically and aligns with the housing
  • Superior NEUTRIK quality standard, extremely robust and reliable
  • Easy and reliable twist lock system
  • Improved kink protection by two-component bushing

Specifications:

Electrical
Contact resistance ≤ 2 mΩ
Dielectric strength > 3 kVac (after mating cycles)
Insulation resistance > 10 GΩ (initially)
Number of electrical contacts 2 + PE
Rating Europe EN 60320-1: 16 A 250 V AC, CBC
Rating USA / Canada cUL 60320-1: 20 A 127 V AC, CBC
Mechanical
Cable O.D. 6mm - 12mm
Lifetime Typically 5’000 mating cycles
Wiresize (mm²) 1.5 – 2.5mm²
Wiresize (AWG) 16 – 12 AWG
Locking device Twist lock
Termination Screw type terminals
Material
Contact plating Ag
Contacts Copper Alloy
Insert Polyamide (PA6.6)
Locking element Zinc diecast
Shell    Polyamide (PA6) / TPE
Strain relief Polyketone
Bushing Polypropylene / TPE
Environmental
Temperature range -33 °C to +80 °C
Protection class IP20
Flammability acc. to UL94 V-0
View PDF brochure for Neutrik NAC3FXXA-W-S powerCON Cable Connector - Power IN - Blue
