Neutrik NC3FRX-B XLR(f) Right Angle Audio Connector - Black and Gold

Neutrik NC3FRX Right Angle XLR Female Connector - Black
Genuine NC3FRX-B Neutrik AG (Liechtenstein) XLR female right angle audio connector. The RX series is the successor to the RC series and is simply the right angle version of the XX range, featuring superior reliability, ease of assembly, with contact integrity and reduction of cable strain.

Added Features in the RX Series
The NC3FRX-B is 3-pole female XLR connector with nickel housing and silver contacts, and some added features. It has 5 different cable outlet positions and a slim line design, giving greater flexibility in its assembly and positioning in the application.

Neutrik Quality
Neutrik is the leading brand in audio connectors and offers quality of the highest standards. Neutrik connectors are used by professional audio technicians and musicians alike.

Features & Benefits

• Extra slim right angle connector
• 5 selectable cable outlet positions
• Unique cage design of female contact for low contact resistance and high integrity
• Female contact incorporates a solder barrier to prevent solder running into the contact mating area
• Female connector with improved solid metal latch which is larger and easier to handle
• Additional ground spring contacts for better shell ground continuity
• Improved chuck type strain relief provides higher pull-out force and makes assembly easier and faster
• Boot with polyurethane gland gives high protection to cable bending stresses
• Colored rings and boots available for coding or identification
• Sleek and ergonomic design - valuable and handy
• Branded with unique hologram- guarantees genuine and authentic Neutrik product

Includes

• 1x Genuine NC3FRX-B connector

Technical Info
FAQ
Assembly Instruction
Drawing (PDF)
