SWAMP Star-Quad Balanced Microphone Cable - Per Metre
SHOP NOW • PAY LATER • 100% INTEREST FREE
Per metre - A star-quad cable containing four cores constructed in a cross formation, with the opposite cores wired together in parallel forming a single balanced pair.
Star-Quad Balanced Microphone Cable - Black - 4 core - Per Metre
A star-quad cable contains four cores constructed in a cross formation, with the opposite cores wired together in parallel forming a single balanced pair. Thus a star-quad cable carries two signals, like a regular balanced 2-core mic cable, but uses 2 cores to carry each signal. The result is a cable that has superior balancing characteristics. Though the extra cores cause an increase in capacitance, resulting in some HF (high frequency) signal loss. Thus, star-quad cables are often used in broadcast applications, where the noiselessness of transmission of voice is critical, and the HF loss is acceptable.
What's special about the braided ground shield?
A braided ground shield gives superior rejection to unwanted RF noise ensuring optimum signal quality. Having a greater shield coverage does mean braided cables are less flexible than regular spiral shield cables. Avoid rolling these cables tightly to prevent cable damage.
- Star-Quad 4 core cable 2x Twisted Pair
- Conductor Cores: 4x (0.38mm*10)
- Ground Core: BRAIDED (0.16mm*8*0.10)
- Outer Diameter: 6.7mm
