Tascam US-4x4HR 4-in/4-out USB Audio Interface with 4 Mic Preamps

24bit/192kHz Resolution

$398.99
In Stock
RRP $479.00

The new series of Tascam USB interfaces employ an Ultra-High Definition discrete architecture mic preamp design with a new enhanced audio circuit. Simple and intuitive, the 4x4HR model has 4 Mic Preamps with combo jack inputs. 24bit/192kHz Resolution.

Tascam US-4x4HR 4-in/4-out USB Audio Interface with 4 Mic Preamps
The new series of Tascam USB interfaces employ an Ultra-High Definition discrete architecture mic preamp design with a new enhanced audio circuit. Simple and intuitive, the 4x4HR model has 4 Mic Preamps with combo jack inputs. 24bit/192kHz Resolution.

Ultra-High Definition Discrete Architecture
Tascam US-4x4HR employs an Ultra-High Definition Discrete Architecture mic preamp design that delivers audio with extremely low self-noise to capture every detail of your musical performances. Because of the wide dynamic range, this interface can also be used with dynamic microphones in addition to condenser mics. This makes it ideal for a variety of applications from recording vocals, pianos and acoustic guitars. With 4 XLR mic inputs and 4 TRS line inputs (IN 1-2 guitar input support) audio interface with implemented MIDI IN/OUT ports. Equipped loopback function and OBS support makes this interface an excellent choice for podcasts and live streaming. The new US-4x4HR offers simple and intuitive operation, sophisticated looks, a rich assortment of software bundles, and improved audio performance with 192 kHz support, thanks to the newly enhanced audio circuit.

Optimal Interface for Home Recording
The US-4x4HR is equipped with 4 mic/line inputs with guitar input support on IN 1-2 plus 2 headphone outputs that can be put to use in various music/multi-media production environments such as vocal/guitar simultaneous recordings and multitrack recordings. The unit is also equipped with a USB-C port to be easily powered by USB bus power.

Zero-Latency Direct Monitoring
Direct monitoring will diverge signals before sending them to the computer, resulting in smooth, in-time monitoring without any sound delay during both recording and performance.

Quality Bundled Software
The US-HR models come bundled with world-renowned software that will enhance the user's production workflow. At the core of music production, Steinberg's Cubase LE/Cubasis LE DAW is included, along IK Multimedia's Sample Tank SE, which comes free of charge with a massive 30GB sound library encompassing more than 2,000 different musical instruments. US-HR models also come with a free 3-month subscription to Auto-Tune Unlimited, a comprehensive suite of industry standard pitch correction and vocal effects.

Interface for Podcasts and Live Streaming
The US-4x4HR can be used with computers or smartphones to easily create podcasts or live streams. The audio can be switched between stereo/mono, and the loopback function allows the audio from the computer to be returned to the streaming software for playback during live streams. US-4x4HR also supports OBS, which is popular and used worldwide.

Equipped with MIDI IN/OUT
The MIDI IN/OUT terminals allow for other MIDI external devices such as keyboards, drum machines, controllers, etc. to be synchronized and controlled.

Compatible with iPad and Other iOS Devices
The US-4x4HR can be used as an interface for iPad and other iOS devices.

New Audio Interface Engine
Capitalizing on our experience of being one of the pioneers in manufacturing USB audio interfaces, we achieved further stability in our native driver. The audio buffer size can be set starting from 4 samples (Windows only) to give the best performance to every different environment; maximizing the capability of the computer in use while creating a low-latency environment.

Robust Metal Casing
The US-HR models share a solid and practical design that has been applied to withstand long hours of hard use. Its robust metal jacket not only improves its durability but, combined with dye-cast aluminum side panels, provides a sleek and eye-catching design. In addition, all models have just the right weight, so they won't move when cables are connected or disconnected.

Features:

  • 4-in/4-out USB audio interface
  • Supports up to 24-bit/ 192kHz audio formats
  • Improved TASCAM driver with selectable buffer size from 4 samples provides low-latency and stability (Windows: TASCAM native driver)
  • 4 XLR/TRS combo inputs equipped with Ultra-HDDA mic preamps and +48V phantom power
  • Combo TRS line inputs with guitar input support on IN1-2
  • TRS line outputs 1-2/3-4
  • Two headphone outputs
  • Equipped with MIDI IN/OUT terminals
  • USB Type-C connection (USB Type-A to Type-C cable included)
  • Powered by USB bus power
  • * 48V phantom power requires PC power supply via USB-C connection.
  • Zero-latency direct monitoring
  • Compatible with iPad and other iOS devices
  • Extensive line-up of bundled software
  • Steinberg Cubase LE, Cubasis LE 3
  • IK Multimedia Sample Tank 4 SE
  • Antares AUTO-TUNE UNLIMITED (available free of charge up to 3 months)
  • Stereo/mono selectable loopback function (Windows, Mac, iOS, iPad OS)
  • OBS support

Specifications:

Sampling frequency 44.1k/48k/88.2k/96k/176.4k/192k Hz
Quantisation bit rate 24bit
Analog audio inputs
MIC IN
Connector XLR-3-31(1:GND, 2:HOT, 3:COLD), BALANCED
Input impedance 2.2k ohms
Maximum input level
(GAIN:MIN)
+9dBu (2.183Vrms)
Gain 56dB
LINE IN * When set to "LINE" at LINE/INST switch
Connector 6.3mm(1/4")TRS-jack(T:HOT, R:COLD, S:GND), BALANCED
Input impedance 10k ohms
Maximum input level
(GAIN:MIN)
+20dBu(7.746Vrms)
Gain 56dB
INSTRUMENT IN * When set to "INST" at LINE/INST switch
Connector 6.3mm(1/4")TS-jack(T:HOT, S:GND), UNBALANCED
Input impedance  1M ohms or more
Maximum input level
(GAIN:MIN)
+10dBV(3.162Vrms)
Gain 56dB
Analog Audio Outputs
LINE OUT 1-2, 3-4
Connector 6.3mm(1/4")TRS-jack(T:HOT, R:COLD, S:GND), BALANCED
Output impedance 210 ohms
Nominal output level +4dBu (1.228Vrms)
Maximum output level +20dBu (7.746Vrms)
PHONES
Connector 6.3mm(1/4") stereo phone jack
Maximum output level 45mW+45mW or more
(THD+N 0.1% or less, 32ohms loaded)
MIDI IN /OUT
Connector Din 5-pin
Format Standard MIDI format
USB
Connector USB Type-C
Format USB2.0 HIGH SPEED (480Mbps)
Power
When connected PC USB bus powered
AC Adapter (TASCAM PS-P1220E, included)
When connected iOS

AC Adapter (TASCAM PS-P1220E, included)

Power consumption 2.25W
Dimensions 296(W) × 65(H) × 160(D)mm (including protrusions)
Weight 3.53lb (1.6kg)
Operating temperature 5 to 35°C
Accessories AC adapter(TASCAM PS-P1220E), USB cables (Type-A to Type-C), Set of DAW software installation guides, Set of DAW plug-in software installation guides, Owner's Manual (including warranty)
View PDF brochure for Tascam US-4x4HR 4-in/4-out USB Audio Interface with 4 Mic Preamps
