Audio-Technica ATM230 Instrument Microphone for Drums
Get Early Access to our FRENZY SALE

Audio-Technica

Audio-Technica ATM230 Dynamic Hypercardioid Toms Drums Instrument Microphone

$239.99
RRP $299.00
BACK-ORDER - DISPATCHED AFTER 30 days
Found a better Price? Price match now
ETA confirmed in <24hr - option to cancel
If your prefer to wait until the stock has arrived:
CLICK HERE TO 'GET NOTIFIED' once we have stock on hand
or interest free for up to 6 months with
-
+

The ATM230 dynamic microphone brings a compact low-profile design with a rugged full metal build to be an excellent toms / snare / percussion microphone. Full high end response for rim shots, and huge low boost detail for drums. Included is a rim mount.




Dispatch

ATM230 Dynamic Hypercardioid Toms Drums Instrument Microphone
The ATM230 dynamic hypercardioid microphone brings a compact low-profile design with a rugged, all metal build to be an excellent floor and rack toms / percussion microphone. The hypercardioid pattern is ideal as the tight polar pattern will reject the sounds from the hats, cymbals and snare. It features a wide spectrum of frequency response, so that full high end response are perfect for rim shots, and importantly a huge low boost detail for the toms / percussive drums. Included is a AT8665 drum/rim mount and a protective cover.

Hypercardioid Polar Pattern
This polar pattern is a variation of the classic cardioid shape, but with a tighter directionality at the front. It also picks up smaller levels of sound from the rear and sides off the capsule, if in close proximity. In this case, the ATM230 will pick up the tom / drums without picking up too much of the snare, hi-hats and cymbals.



Features:
Hypercardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
Handles very high SPL at close range
Big, warm low-frequency response with excellent attack
Low-profile design permits versatile placement around drum kit
Rugged, all-metal design and construction for years of trouble-free use
Includes AT8665 drum mount and a soft protective pouch
Also available as a 3-Pack (ATM230PK)


Specifications:

ELEMENT Dynamic
POLAR PATTERN Hypercardioid
FREQUENCY RESPONSE 30-12,000Hz
OPEN CIRCUIT SENSITIVITY –54dB (1.9 mV) re 1V at 1Pa
IMPEDANCE 600ohms
WEIGHT 292g (10.3 oz)
DIMENSIONS 82.5mm (3.2") long,
38.0mm (1.5") maximum diameter
OUTPUT CONNECTOR Integral 3-pin XLRM-type
ACCESSORIES FURNISHED AT8665 drum mount for 5/8"-27 threaded
adaptor; 5/8"-27 to 3/8"-16 threaded
adaptor; soft protective pouch
AUDIO-TECHNICA CASE STYLE R2
