Audio-Technica ATM450 Cardioid Condenser Side Address Instrument Microphone

$259.99
Sold Out
Contact us for an ETA
RRP $325.00

A small diaphragm condenser mic with a side address design, a low end bass filter, and a -10dB pad switch, useful for close miking of loud sound sources. It ships with a mic clip, a windsock, and a pouch. Ideal for drums and acoustic instruments.

ATM450 Cardioid Condenser Side Address Instrument Microphone
This excellent microphone is a small diaphragm condenser mic with a side address pencil design, a low end bass filter, and a -10dB pad switch, which is useful for close miking of loud sound sources. The design form factor makes this mic an ideal one for tight placement options, especially keeping out of the way from the performer. The ATM450 is ideal for close drum miking, either as overheads, or on individual parts. With a frequency response from 40Hz to 20kHz, the ATM450 is ideal for high sound pressure levels, and sound pickup from amplified acoustic instruments. It ships with a dedicated mic clip, a windsock, and a protective pouch.

Cardioid Polar Pattern
This polar pattern is ideal for live and studio use of acoustic instruments and drums and percussion. The mic's pick up range is 180 degrees in front of the microphone. The cardioid polar pattern of the microphone is more sensitive to sound originating directly in front of the element, making it useful in controlling feedback, reducing pickup of unwanted sounds and providing isolation between performers. Cardioid mics are used for a very high percentage of microphone applications

.

Features:

  • Unique side-address stick design maximizes placement options with minimal obstructions
  • Uncompromising sound quality for overheads, percussion, acoustic guitar, strings and other acoustic instruments
  • Integral 80Hz HPF switch and 10dB pad
  • Durable performance for professional applications
  • Cardioid polar pattern reduces pickup of sounds from the sides and rear, improving isolation of desired sound source
  • Rugged, all-metal design and construction for years of trouble-free use
  • Includes isolation clamp for shock protection, secure mounting and easy positioning


Specifications:

ELEMENT Fixed-charge back plate permanently polarized condenser
POLAR PATTERN Cardioid
FREQUENCY RESPONSE 40-20,000Hz
LOW FREQUENCY ROLL-OFF 80Hz, 18dB/octave
OPEN CIRCUIT SENSITIVITY –41dB (8.9 mV) re 1V at 1Pa
IMPEDANCE 200 ohms
MAXIMUM INPUT SOUND LEVEL 152dB SPL, 1kHz at 1% T.H.D.
DYNAMIC RANGE (typical) 127dB, 1kHz at Max SPL
SIGNAL-TO-NOISE RATIO 69dB, 1kHz at 1Pa
PHANTOM POWER REQUIREMENTS 11-52V DC, 3.5mA typical
SWITCHES Flat, roll-off; 10dB pad
WEIGHT 98g (3.5 oz)
DIMENSIONS 126.9mm (5.00") long,
21.0mm (0.83") diameter
OUTPUT CONNECTOR Integral 3-pin XLRM-type
ACCESSORIES FURNISHED AT8471 isolation clamp for 5/8"-27 threaded stands; 5/8"-27 to 3/8"-16 threaded adapter; windscreen; soft protective pouch
AUDIO-TECHNICA CASE STYLE S11
View PDF brochure for Audio-Technica ATM450 Cardioid Condenser Side Address Instrument Microphone
