JOYO R-16 Vocal Lab Harmony Guitar Effects Pedal

JOYO

JOYO R-16 Vocal Lab Harmony Guitar Effects Pedal

$248.99
  In Stock
Found a better Price? Price match now
or interest free for up to 6 months with
-
+

JOYO's first vocal effects pedal especially designed for guitarists. There are 9 different musical presets, providing a variety of interval tracking, as well as reverbs, all keys available with major/minor toggling, XLR I/O, 48V power and much more!

Dispatch

JOYO R-16 Vocal Lab Harmony Guitar Effects Pedal
JOYO's first vocal effects pedal especially designed for guitarists. There are 9 different musical presets, providing a variety of interval tracking, as well as reverbs, all keys available with major/minor toggling, XLR I/O, 48V power and much more!

Musical and Functional
All of the harmonising effects on the JOYO Vocal Lab can be mixed, adjusting the ratio of dry sound (natural) and applying the wet signal of the selected harmony. The more you turn the mix to the right the dry fades away and more harmonics are applied, mixed together or removed away this is where the harmonising fun begins! With a rotary encoder the vocal lab can process your vocals to 12 different keys, select C,D,E,F,G,A & B and by pressing the dial you get the # (not for E or B though!) A Major / Minor toggle switch to adjust your scale. The LED Display indicates the selected key. The controls to adjust the microphone gain has a useful LED overload indicator built in enabling you to adjust the input. When the microphone  is active and this dial lights green the signal is clean and there will be no overdrive, yellow is a warning and red will be overdriven and potentially distorting the vocal input.

More Features
A 3 mode Reverb control can be adjusted and turned on or off with the footswitch on the right. The footswitch on the left activates the Harmonic selection, both can be used independently of each other and each will light when active. On the side there is a switch to turn off/on 48v phantom power for using condenser microphones.

More Connections
On the rear of the pedal there is a 1/4” mono instrument input, perfect for connecting your guitar or keyboard. This also has the feature of using the reverb effect, but will not process the harmonic of the instrument. The Aux in 3.5mm stereo input will allow you to connect up your phone/tablet or mp3 player to sing & play along to. What is special about this is the centre silencer button that will strip out vocals (from the centre) from the music, giving you a vocal free music experience. Whilst this is not suitable for all tracks, the principle is that when the centre silence is activated the right input of the stereo aux in is sent out of phase, its put back together and is removed from playback. The 3.5mm stereo headphone is a great feature, allowing you to monitor and fine tune your vocal processing.

NOTE: 1000mA/1A 9V power supply is required. This has been incorrectly written as 500mA in the manual by JOYO.

Features:

  • 9 position vocal harmony selection
  • 3 position vocal reverb - small, medium and large
  • 12 Keys are available with Major/Minor toggle switch
  • Selectable 48V phantom power supply On/Off for microphones
  • Harmony and Reverb Footswitches.
  • Harmony Mix control
  • Microphone Gain control with response indicator

9 Effect Types:

1. Unison
Adjust the MIC Input’s Vocal pitch, and the HARMONY EFFECTS
was delayed for a bit, obtaining Unison effect of many people.
2. Low 4th below
3. High 3rd above
4. Low & High 3rd above, a perfect 4th below
5. Lower 6th below
6. Higher a perfect 5th above
7. Lower & Higher 6th below, a perfect 5th above
8. Low & Lower a perfect 4th below, and a 6th below
9. High & Higher 3rd above, and a perfect 5th above



Specifications:

Effect type Harmony and Reverb
Harmony numbers 9
Controls Harmony, Key Select, Reverb, Har.mix, Mic.gain,
Footswitch 2
Toggle Major/Minor
Input Jack 6.35mm
Output Jack 6.35mm
Instrument Input Impedance 1MΩ / 6.35mm
MIC Input Impedance 2.49 KΩ / XLR
Headphone Output Impedance 32Ω / 3.5mm
MIC Output Impedance 600Ω / XLR
AUX IN Impedance 10KΩ / 3.5mm
Working Current 1000mA (incorrectly written as 500mA in manual)
Working Voltage DC 9V (Center minus)
Signal Bypass Type Bypass
LED Mod Sync, Always, Off
Battery powered No
Phantom power 48V
Dimensions 130x110x50mm
Weight 416g
